AI296 Version 9.8x User’s Guide
Product Description: Typical Applications
1-13
illustrates the following events:
z
The SNMP Network Manager (for example, AppliedView) sends TCP/IP calls over
an IP/Ethernet network to AIswitch (AI296).
z
AI296 encapsulates the TCP/IP calls within X.25 SVC calls and sends them
through the X.25 packet network.
z
The X.25 packet network sends the X.25 calls to a remote AIswitch (AI296).
z
The remote AI296 returns the X.25 calls to TCP/IP calls based on its static routing
tables.
z
AI296 sends the TCP/IP calls over the IP/Ethernet network to the
SNMP-managed device (for example, AI198).
