Kentrox AI296 User Manual
Page 182
AI296 Version 9.8x User’s Guide
Link Configuration: Virtual Circuit Configuration
6-88
2. Enter a value (
02
through
15
) associated with the PVC to be configured. Menu
4.2.11.12.9.2.1 (the PVC Edit Menu) appears.
3. For
01*PVC Type
, enter
1
to select
Passive
,
Active
, or
Connect on activity
. The default
is
Passive
.
4. For
02 LCN Low
, enter
2,
and the minimum LCN value. Valid values are
1
to
1024
.
The default is
1
.
Note: An asterisk (
*
) configures all LCNs for the link with values defined in menu
item 4.2.1114.12.9.1.
5. For
03 LCN High
, enter
3,
and the maximum LCN value. Valid values are
1
to
1024
.
The default is
1
.
6. For
04 RESET Timer Interval
, enter
4,
and the reset timer interval value.
The timer type, range, and default settings depend on the PVC type. Refer to
for PVC types, timer types, ranges, and defaults.
>3
Menu 4.2.11.12.9.2.1
01*PVC Type (Passive, Active, Connect on activity)----------------------Passive
02 LCN Low (* for all LCNs for the link)-----------------------------------0001
03 LCN High----------------------------------------------------------------0001
04 RESET Timer Interval (seconds)-----------------------------------------00000
20 Save the changes made
21 Exit this menu with no changes
Enter item number and optional ",value" then push
>
Table 6-1 PVC and Timer Type
PVC Type
Timer Type
Range
Default
Active
Call Timer
30 to 600 s
30 s
Connect on Activity
Inactivity Timer
1 to 600 s
1 s
