3.1 Administration Window
25
Figure 3.1 The main window of Administration Console for WinRoute
Administration Window — Main menu
The main menu provides the following options:
File
• Reconnect — reconnection to the WinRoute Firewall Engine after a connection
drop-out (caused for example by a restart of the Engine or by a network error).
• New connection — opens the main window of the Administration Console. Use
a bookmark or the login dialog to connect to a server.
This option can be useful when the console will be used for administration of
multiple server applications (e.g. WinRoute at multiple servers). For details, refer
to the Help section in the Administration Console manual.
Note: The New Connection option opens the same dialog as running the Adminis-
tration Console from the Start menu.
• Quit — this option terminates the session (users are logged out of the server and
the administration window is closed). The same effect can be obtained by clicking
the little cross in the upper right corner of the window or pressing Alt+F4 or
Ctrl+Q.
Edit
Options under Edit are related to product registration and licensing. The options available
in the menu depend on the registration status (for example, if the product is registered
as a trial version, it is possible to use options of registration of a purchased license or
a change of registration data).
