SECTION 6: ON LINE

Page 6-6

SATO HT200e

CONFIGURATION FOR DATA TO BE TRANSMITTED

Command for specifying medium
Where print parameter or preset data is sent, for each data to be transmitted, SOH + medium
assignment shall be sent as header and EOT be transmitted as trailer. This sending is not on
a field unit basis, and each command should be put at the head and end as described.

Print parameter: It can be sent with DATA STORE/RECALL in data maintenance mode.
For one format, data to be transmitted will be enclosed within STX to ETX and sent on a unit
format basis.

(Up to 30 fields)

Important: The last field shall be set as the field for the number of paper. Parenthesis shows

the number of byte for each term.

SOH

Medium assignment

Description on data to be transmitted

“7”

Data on print parameter for HT200e

“9”

Preset data:
The number can voluntarily be established from 0001 to 9999.

“H”

Data for table 1:
The number can be assigned from 001 to 200.

“I”

Data for table 2:
The number can be assigned from 001 to 200.

“J”

Data for table 3:
The number can be assigned from 001 to 500.

SOH

STX Format No. (2)

Data regulating print position (12)

Name of format (10)

Name of label (10)

Format No. (2) Item name (10) Parameter (46) Fixed data (32)

ETX

STX

Format No. (2)

Data regulating print position (12)

Name of format (10)

Name of label (10)

Format No. (2) Item name (10) Parameter (46) Fixed data (32)

ETX EOT

One fo

rmat
