Welcome to the SIMATIC Box PC 620
2-6
SIMATIC Box PC 620 Manual
A5E00131465-01
2.4
Side View
2
3
1
Figure 2-4 Side View
1 Mounting possibilities for the WinAC Backup Battery
You can mount the SIMATIC WinAC CPU41x-2PCI backup battery here. Use the
battery holder without a slot plate supplied with the WinAC module to do this.
2 Input Data of Power Supply Unit
To distinguish between both performances of the power supply unit, the power sup-
ply unit with a 105W performance been marked with P
max=
105W.
3 Certificate of Authenticity with Product Key
You need the Microsoft Windows “Product Key” on the “Certificate of Authenticity”
if you reinstall software.
