Configuring the SIMATIC Box PC 620
5-30
SIMATIC Box PC 620 Manual
A5E00131465-01
Systemparameter YourEntries Default Settings
Fan Control Enabled
CRT/LCD selection SIMULTAN
LCD Screensize Expanded
DSTN Contrast 154
PS2 Mouse Enabled
Advanced
COM/LPT Configuration
Internal COM1
Enabled
Base I/O address 3F8
Interupt IRQ4
Internal COM2 Enabled
Base I/O address 2F8
Interrupt IRQ3
Internal LPT1 Enabled
Mode Bi-directional
Base I/O address 378
Interrupt IRQ7
DMA Channel (nur bei ECP) DMA 3
PCI-Configuration
PCI Device Slot 1
Option ROM Scan
Enabled
Enable Master Enabled
Latency timer 0040 h
PCI Device Slot 2
Option ROM Scan
Enabled
Enable Master Enabled
Latency timer 0040 h
PCI/PnP ISA IRQ Exclusuion
IRQ3
Available
IRQ4 Available
IRQ5 Available
IRQ9 Available
IRQ10 Available
IRQ11 Reserved
PCI IRQ Line 1 Auto Select
PCI IRQ Line 2 Auto Select
PCI IRQ Line 3 Auto Select
PCI IRQ Line 4 Auto Select
Installed O/S Other
Reset Configuration Data No
Floppy disk controller Enabled
Local Bus IDE adapter Both
Large Disk Access Mode DOS
Hard Disk Pre-Delay Disabled
Memory Gap at 15 Mbyte Disabled
