Error Diagnosis
6-6
SIMATIC Box PC 620 Manual
A5E00131465-01
6.7 An Error Message Appears on the Screen
Error Messages
The following table describes the error messages that the BIOS system outputs.
Error messages the operating system or program outputs are described in the
manuals for these programs.
Press to call Setup when booting the computer.
Error Message on the Screen Meaning/Suggestion
Address conflict Plug and Play Problem
Contact your technical support team.
Combination not supported Plug and Play Problem
Contact your technical support team
IO device IRQ conflict Plug and Play Problem
Contact your technical support team
Invalid System Configuration
Data
Plug and Play Problem
Please set the option RESET CONFIGURATION.DATA in the
Advanced Setup menu.
Contact your technical support team
Allocation Error for ... Plug and Play Problem
Please undo the last hardware change.
Contact your technical support team
System battery is dead
Replace and run SETUP
The battery on the CPU module is defective or dead.
Contact your technical support team
System CMOS checksum bad
Run SETUP
Call up SETUP, adjust settings and save. If this message appears
during each power up, contact your technical support team.
Incorrect Drive A type
Run SETUP
Check the SETUP entries for drive A.
Incorrect Drive B type
Run SETUP
Check the SETUP entries for drive B.
Diskette drive A error Error accessing drive A.
Contact your technical support team.
Diskette drive B error Error accessing drive B.
Contact your technical support team.
Failure Fixed Disk Error accessing the hard drive.
Check the SETUP settings
Contact your technical support team.
Keyboard error Check whether the keyboard is connected correctly.
Stuck Key Check whether a key on the keyboard is stuck.
System RAM Failed at offset: Memory error
Contact your technical support team.
Shadow RAM Failed at offset: Memory error
Contact your technical support team
Extended RAM Failed at offset: Memory error
Contact your technical support team
Failing Bits: Memory error
Contact your technical support team
