Reinstallation of the Software
8-7
SIMATIC Box PC 620 Manual
A5E00131465-01
8. After data transfer and end message acknowledgement Windows 98 setup can
be started directly using the
LW:\WIN98\SETUP.EXE program. (LW: Drive to which the WIN98 folder has
been transferred).
9. After having started setup.exe please follow the screen instructions.
8.2.2
Installing the Recovery CD for Microsoft Windows NT
This CD contains encoded data which can only be transferred to a SIEMENS
SIMATIC PC.
Data transfer is carried out with the OEMSETUP.EXE program on the CD ROM or,
after booting, from the CD-ROM with the recovery function.
After transferring the required data to the hard disk, the operating system can be
installed using the Windows NT setup program.
Windows NT Installation Sequence
If a Windows operating system is already installed or if the PC has been started
with a user created bootdisk, data transfer takes place using the OEMSETUP.EXE
program. To do this, start the OEMSETUP.EXE program in the root directory of the
Recovery CD and continue the sequence as of point 5.
If there is no operating system installed, proceed as follows:
1. Insert the Recovery CD in the CD ROM drive and reboot the system.
2. To boot from the CD proceed as follows: When the message
Press
appears on the screen press the ESC key. After intialization a boot menu to
select the boot options is displayed.
3. Select ”ATAPI CD ROM Drive”.
4. When “Microsoft Windows 98-Startup Menu” is displayed, select
“1. Boot for CD-Recovery”.
If the hard disk has not been installed, first select “2. Boot for FDISK, FORMAT
or Windows Setup” (Section 8.1).
5. You have to acknowledge the “SIEMENS End User License Agreement” with
the F8 function key. Pressing ESC allows you to decline the agreement and
cancels the installation.
6. In the next screen you can select the components which are to be copied from
the CD to the hard disk. Transfer of at least the folder “I386” is necessary for
the Windows NT installation or setup.
7. Select the drive for data transfer. The selected drive is not the installation drive
for Windows. For the Windows setup, you need an available disk space of
approximately 300 MB on the installation drive for Windows.
