3-9-5. Multicast Status
Function name:
Multicast Status
Function description:
The Multicast Status function allows to display the switch received multicast
traffic status. If the switch doesn’t receive any multicast traffic then it will
display the “No multicast entry !”
Fig. 3-24
Parameter description:
No:
To display current built-up multicast group entry index.
Group Address :
To display current built-up multicast Group Address
VID:
To display current built-up multicast VLAN ID .
Port Members:
To display current built-up multicast port members .
Previous Page:
To display previous page context.
Next Page:
To display next page context.
Refresh:
To Update multicast group membership.
