ICP DAS USA MSM-6226 - Manual (Page 18)

Publication date:March., 2011
Revision A1
6
1-4. View of MSM-6226
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 24 TP Fast Ethernet ports and 2 slots for optional removable
modules on the front panel of the switch. LED display area, locating on the front
panel, contains a CPURUN, Power LED and 26 ports working status of the switch.
Fig. 1-1 Full View of MSM-6226D with SFP Module
Fig. 1-2 Front View of MSM-6226 with SFP Module
Power Indication
Fast Ethernet LED SET Mode: ACT/FDX/SPD
Gigabit Dual Media Port:
TP Port Status:
TP Port Status: Link
LEDSET Button
LEDSET button
is used to
change the LED
display mode
RESET Button:
RESET button is used to
reset the management
system.
