Figure 4. (a-c) ac’97 connections – Intel CHIPSET 820E User Manual
Page 24
Intel
®
820E Chipset
R
24
Design
Guide
Figure 4. (A-C) AC’97 Connections
4A. AC'97 with Audio Codecs (4-Channel Secondary)
4B. AC'97 with Modem and Audio Codecs
4C. AC'97 with Audio/Modem Codec
ICH2 360
EBGA
AC’97
Audio
Codec
AC’97 Digital
Link
AC’97
Audio
Codec
Audio Port
Audio Port
ICH2 360
EBGA
AC’97
Modem
Codec
Modem Port
Audio Port
AC’97 Digital
Link
AC’97
Audio/
Codec
ICH2 360
EBGA
AC’97 Digital
Link
AC97_conn
AC’97
Audio/
Modem
Codec
Audio Port
Modem Port
