3.3. Theory
3.3.1. AGTL+
AGTL+ is the electrical bus technology used for the processor bus. This is an incident wave switching,
open-drain bus with external pull-up resistors that provide both the high logic level and termination at
each load. The processor AGTL+ drivers contain a full-cycle active pull-up device to improve system
timings. The AGTL+ specification defines the following:
•
Termination voltage (V
TT
)
•
Receiver reference voltage (V
REF
) as a function of termination voltage (V
TT
)
•
Processor termination resistance (R
TT
)
•
Input low voltage (V
IL
)
•
Input high voltage (V
IH
)
•
NMOS on resistance (R
ON
N
)
•
PMOS on resistance (R
ON
P
)
•
Edge rate specifications
•
Ringback specifications
•
Overshoot/undershoot specifications.
•
Settling limit
3.3.2. Timing
Requirements
The system timing for AGTL+ depends on many things. The following elements combine to determine
the maximum and minimum frequencies supportable by the AGTL+ bus:
•
Timing range for each agent in the system
Clock to output [T
CO
] (Note that the system load is likely to differ from the “specification”
load, so the T
CO
observed in the system might differ from the T
CO
of the specification.)
Minimum required setup time to clock [T
SU_MIN
] for each receiving agent
•
Range of flight time between each component, including
Propagation velocity for the loaded printed circuit board [S
EFF
]
Board loading effect on the effective T
CO
in the system
•
Amount of skew and jitter in system clock generation and distribution
•
Changes in flight time due to crosstalk, noise, and other effects
