169
3 TXD -----------TXD ----------> 2 RxD
5 SGND -----------SGND ---------- 5 SGND
Cables
The RJ-45 ports on the switch support automatic MDI/MDI-X operation, so you can use
standard straight-through twisted-pair cables to connect to any other network device (PCs,
servers, switches, routers, or hubs). Please refer to the following table for cable
specifications.
Cable Types and Specifications
Cable Type Max. Length Connector
10BASE-T Cat. 3, 4, 5100-ohm UTP 100 m (328 ft) RJ-45
100BASE-TX Cat. 5 100-ohm UTP 100 m (328 ft) RJ-45
1000BASE-SX
50/125 or 62.5/125 micron
core multimode fiber (MMF)
300/550m LC
1000Base-LX
8.3/125 micron single mode
(SMF)
10Km LC
Cable specification table
100BASE-TX/10BASE-T Pin Assignments
With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins
3 and 6 for receiving data.
RJ-45 Pin Assignments
