158
Output Voltage: display the current value, minimum, and maximum value of
UPS output voltage.
Frequency: display the frequency value of UPS.
Battery Capacity: display the battery capacity of UPS.
UPS Overload: display the overload capacity of UPS.
Temperature: display the current temperature of UPS.
RatVoltage: range of the UPS voltage.
RatBtyVoltage: range of the UPS battery voltage.
RatCurrent: range of the UPS current.
RatFrequency: range of the UPS frequency.
Company Name: Name of UPS Company.
Model: model name of the UPS.
Version: UPS internal software version.
POE Status
You can view POE port information and set configuration to each port. Select the port and
set configuration and click the Apply button to apply new value. Click the Refresh
button to get current POE status.
The figure represents the UPS status, when the status has
been detected, the figure color change from yellow to red and
the status description will changed.
