9
Green
The POE Injector function is on and
power is forwarding the attached PD
device.
Power Forwarding
Off The POE injector function disables.
1000(Giga port)
25 & 26 port
Green In 1000Mbps connection speed
100(Giga port)
25 & 26 port
Orange In 100Mbps connection speed
Green The port is connecting with the device.
Blink
The port is receiving or transmitting
data.
LNK/ACT (Giga
port)
25 & 26 port
Off No device attached
Orange
The port is operating in Full-duplex
mode
Blink Collision of Packets occurs in the port
FDX/COL (Giga
port)
25 & 26 port
Off In half-duplex mode
