Refer to the following table and set the parameters:
Setting
Signal
Name
Functions Related Parameters
Pr. 59 = "0"
Low-speed operation
command
Pr. 4 to Pr. 6, Pr. 24 to Pr. 27,
Pr. 80 to Pr. 87
0 RL
Pr. 59 = "1", "2" (*1)
Remote setting
(setting clear)
Pr. 59
Pr. 59 = "0"
Middle-speed
operation command
Pr. 4 to Pr. 6, Pr.24 to Pr. 27,
Pr.80 to Pr. 87
1 RM
Pr. 59 = "1", "2" (*1)
Remote setting
(deceleration)
Pr. 59
Pr. 59 = "0"
High-speed operation
command
Pr. 4 to Pr. 6, Pr. 24 to Pr. 27,
Pr. 80 to Pr. 87
2 RH
Pr. 59 = "1", "2" (*1)
Remote setting
(acceleration)
Pr. 59
3 RT Second function selection Pr. 44 to Pr. 47
4 AU Current input selection

5 STOP Start self-holding selection

6 MRS Output shut-off stop

7 OH
External thermal relay input (*2)
The inverter stops when the externally
provided overheat protection thermal
relay, motor's embedded temperature
relay etc. is actuated.
Refer to page 140.
8 REX
15-speed selection (combination with 3
speeds RL, RM, RH) (*3) Pr. 4 to Pr. 6, Pr. 24 to Pr. 27,
Pr. 80 to Pr. 87
9 JOG Jog operation selection Pr. 15, Pr. 16
10 RES Reset Pr. 75
14 X14 PID control presence/absence selection Pr. 88 to Pr. 94
16 X16 PU-external operation switch-over Pr. 79 (setting: 8)
- - - STR Reverse rotation start
(can be assigned to STR
terminal (Pr. 63) only)
*1 When Pr. 59 = "1 or 2", the functions of the RL, RM and RH signals change as
listed above.
*2 Actuated when the relay contact "opens".
*3 When using the REX signal, an external command cannot be used to make a
reverse rotation start.
REMARKS
•
One function can be assigned to two or more terminals. In this case, the function
is activated when one of the multiple terminals used for assignment turns on.
•
The speed command priorities are higher in order of jog, multi-speed setting (RH,
RM, RL, REX) and AU.
•
Use common terminals to assign multi-speeds (7 speeds) and remote setting.
They cannot be set individually.
(Common terminals are used since these functions are designed for speed
setting and need not be set at the same time.)
