.3.12 Stall prevention function and current limit function
You can make settings to disable stall prevention caused by overcurrent and to
disable the fast-response current limit (which limits the current to prevent the
inverter from resulting in an overcurrent trip if an excessive current occurs due to
sudden load variation or ON-OFF, etc. in the output side of the running inverter).
•
Stall prevention
If the current exceeds the limit value, the output frequency of the inverter is
automatically varied to reduce the current.
•
Fast-response Current limit
If the current exceeds the limit value, the output of the inverter is shut off to
prevent an overcurrent.
