30
DC injection
brake operation
time Pr. 11
Out
put
f
requency
Starting frequency
Pr.13
(*1)
0.5Hz
ON
DC injection brake
operation
frequency Pr. 10
3Hz
0.5s
DC injection
brake operation
time Pr. 11
0.5Hz
0.5s
ON
0.5Hz
ON
3Hz
Coasted to
a stop
Time
DC injection brake
not operated
DC injection brake disabled DC injection brake enabled
Start signal
terminal
Across STF-SD
Across STR-SD
(*4)
(*3) (*3)
(*2)
Start/Stop Timing Chart (for two-wire type)
Out
put
f
requ
en
c
y
Starting
frequency
Pr.13
(*1)
0.5Hz
Forward
rotation
Forward
rotation
3Hz
3Hz
Start signal switched on
while DC injection brake
is being operated
DC injection brake operation
frequency Pr. 10
DC injection
brake enabled
Time
DC injection brake
operation time Pr. 11
0.5s
ON
ON ON
ON
Reverse
rotation
0.5Hz
Start
signal
terminal
Across
STF-SD
Across
STR-SD
(*3)
(*4)
Forward-Reverse Rotation Switch-Over Timing Chart
REMARKS
*1 The "starting frequency" in Pr. 13 (factory-set to 0.5Hz) may be set between 0
and 60Hz.
*2. If the next start signal is given during DC injection brake operation, the DC
injection brake is disabled and restart is made.
*3. The "DC injection brake operation time" in Pr. 11 (factory-set to 0.5s) may be
set between 0 and 10s.
*4. The frequency at which the motor is coasted to a stop is not more than the "DC
injection brake operation frequency" set in Pr. 10 (factory setting = 3Hz; may be
set between 0 and 120Hz) or not more than 0.5Hz.
*5. The "starting frequency" in Pr. 13, "DC injection brake operation time" in Pr. 11
and "DC injection brake operation frequency" in Pr. 10 are the factory-set
values.
