50
Func-
tion
Pa-
rame-
ter
Indica-
tion
Name Setting Range
Minimum
Setting
Increments
Factory
Setting
Refer
To:
Cus-
tomer
Setting
60
RL terminal
function
selection
1 0 88
61
RM terminal
function
selection
1 1 88
62
RH terminal
function
selection
1 2 88
63
STR terminal
function
selection
0: RL, 1: RM, 2: RH,
3: RT, 4: AU, 5: STOP,
6: MRS, 7: OH,
8: REX, 9: JOG,
10: RES, 14: X14,
16: X16,
- - -: STR (May be
assigned to the STR
terminal only)
1 - - - 88
64
RUN terminal
function
selection
1 0 90
65
A, B, C
terminal
function
selection
0: RUN, 1: SU, 3: OL,
4: FU, 11: RY, 12: Y12,
13: Y13, 14: FDN,
15: FUP, 16: RL,
98: LF, 99: ABC
1 99 90
66 Retry selection
0: OC1 to 3, OV1 to 3,
THM, THT, GF,
OHT, OLT, PE, OPT
1: OC1 to 3,
2: OV1 to 3,
3: OC1 to 3, OV1 to 3
1 0 91
67
Number of
retries at alarm
occurrence
0: No retry
1 to 10:
Without alarm output
during retry operation
101 to 110:
With alarm output
during retry operation
1 0 91
68
Retry waiting
time
0.1 to 360s 0.1s 1s 91
69
Retry count
display erase 0: Cumulative count
erase
1 0 91
70 *
Soft-PWM
setting 0: Soft-PWM invalid,
1: Soft-PWM valid
1 1 92
71 Applied motor
0: Thermal characteristic
for standard motor
1: Thermal characteristic
for Mitsubishi
constant-torque motor
1 0 93
72 *
PWM
frequency
selection
0 to 15 1 1 92
Ter
m
in
al
f
u
nc
tio
n
s
e
le
c
ti
o
n
73
0-5V/0-10V
selection 0: For 0 to 5VDC input
1: For 0 to 10VDC input
1 0 93
Pammet
e
r Li
s
t
