28

Note:

If a custom collar is to

be used, order ZWCD1 trim kit.
If a custom handle is to be used,
order ZKHT1 trim kit.

Important:

When the bottom

trim piece is removed, an
aluminum shim secured to the
bottom of the door can be seen.
Do not attempt to remove this
piece.

42" Models

Step 2
Install
3/4" trim

OPTION 1
For non-dispenser
model
or dispenser model
using custom
collar trim

Step 1
Remove
handles & trim

• Open door to 90

°

.

• Remove the Phillips head screws from the full-length

handles.

• Open the doors fully to stop.
• Remove the screws from the aluminum trim, top,

bottom and hinge side.

• Retain screws. Discard original trim.

• Attach the new 3/4" trim pieces on the top, hinge side

and bottom using original screws.

ZKT42 Trim Kit

3/4" Custom Panels

ZKT42

INSTALLATION
