WARNING

WARNING

• Il ne faut utiliser cet appareil que pour l’usage pour

lequel il a été construit.

• Il faut réparer ou remplacer immédiatement tout

cordon d’alimentation électrique effiloché ou
endommagé.

• Débrancher le réfrigérateur avant le nettoyage ou

toute intervention.

• Les réparations doivent être faites par un

technicien qualifié.

CAUTION

ATTENTION

Cet appareil doit être correctement mis à la terre.
Consulter « Mise à terre du réfrigérateur », page 15.

• Use this appliance only for its intended purpose.
• Immediately repair or replace electric service

cords that have become frayed or damaged.

• Unplug the refrigerator before cleaning or making

repairs.

• Repairs should be made by a qualified service

technician.

ATTENTION

This appliance must be properly grounded. See “Grounding the Refrigerator,” page 15.

Before you begin - Read these instructions completely and carefully.
IMPORTANT - Save these instructions for local inspector’s use.
IMPORTANT - OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer - Be sure to leave these instructions with the Consumer.
Note to Consumer - Keep these instructions with your Use and Care Book for future reference.

2

Contents

Design Information
Advance Planning for a Flush Installation ................................................................................................................................... 3
Cutout and Product Dimensions .................................................................................................................................................. 3
Installation Between Base & Wall Cabinets ............................................................................................................................. 4
Installation At End-of-Run ............................................................................................................................................................. 4
Frameless Cabinets ........................................................................................................................................................................ 4
Accessory Panel Kits ..................................................................................................................................................................... 4
Advance Planning, Exterior Appearance Options ...................................................................................................................... 5
Appearance Examples, Trim Kit Descriptions ........................................................................................................................... 5
Custom Panel Dimensions
ZIS42N ............................................................................................................................................................................................ 6-9
ZISW36D, ZISB36D .................................................................................................................................................................. 10-13
Side Panel or Filler Options ........................................................................................................................................................ 14
Installation Instructions ........................................................................................................................................................... 15-20
Trim Kits
ZKH1 Trim Kit Installation Instructions
Custom Handles with 1/4" Thick Panels ............................................................................................................................. 21-25
ZG2 Trim Kit Installation Instructions
Grille Panel Frame Adjustment .................................................................................................................................................. 26
ZKT42 Trim Kit Installation Instructions
3/4" Thick Custom Panels ....................................................................................................................................................... 27-32
ZKHT1 Trim kit Installation Instructions
Custom Handles with 3/4" Thick Panels .............................................................................................................................. 33-37
ZKHSS1 Trim Kit Installation Instructions
Tubular Stainless Steel Handles for 1/4" Panel Installation ............................................................................................ 38-41
ZKHTSS1 Trim Kit Installation Instructions
Tubular Stainless Steel Handles for 3/4" Panel Installation ............................................................................................ 42-45
ZWCD1 Trim Kit Installation Instructions
Custom Dispenser Collar ........................................................................................................................................................ 46-47

If you have a question concerning the installation of this
product, call the GE Answer Center

®

Consumer

Information Service at 800.626.2000, 24 hours a day,
7 days a week.

If you received a damaged refrigerator, you should
immediately contact your dealer or builder.

Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the GE Appliance Warranty. See the
Use & Care Guide for warranty information.

For Monogram local service in your area,
1-800-444-1845.
For Monogram service in Canada, 1-888-880-3030.
For Monogram Parts and Accessories, call
1-800-626-2002.
