MAXQ612/MAXQ622 User’s Guide
5-26
Maxim Integrated
REGISTER
DESCRIPTION
I2CST (01h, 04h)
I
2
C Status Register (16-bit register)
Initialization:
This register is cleared to 0000h on all forms of reset .
Read/Write Access:
Unrestricted read . Not all the bits can be written by software . For each bit accessibility refer
to individual bit description .
I2CST.0 (I2CSRI)
I
2
C START Interrupt Flag. This bit is set to 1 when a START condition (S or Sr) is detected .
This bit must be cleared to 0 by software once set . Setting this bit to 1 by software causes
an interrupt if enabled .
I2CST.1 (I2CTXI)
I
2
C Transmit Complete Interrupt Flag. This bit indicates that an address or a data byte
has been successfully shifted out and the I
2
C controller has received an acknowledgment
from the receiver (NACK or ACK) . This bit must be cleared by software once set . Setting
this bit to 1 by software causes an interrupt if enabled .
I2CST.2 (I2CRXI)
I
2
C Receive Ready Interrupt Flag. This bit indicates that a data byte has been received
in the I
2
C buffer . This bit must be cleared by software once set . Setting this bit to 1 by
hardware causes an interrupt if enabled . This bit is set by hardware only .
I2CST.3 (I2CSTRI)
I
2
C Clock Stretch Interrupt Flag. This bit indicates that the I
2
C controller is operating
with clock stretching enabled and is holding the SCL clock signal low . The I
2
C controller
releases SCL after this bit has been cleared to 0 . Setting this bit to 1 by hardware causes
an interrupt if enabled . This bit must be cleared to 0 by software once set . This bit is set by
hardware only .
I2CST.4 (I2CTOI)
I
2
C Timeout Interrupt Flag. This bit is set to 1 if either the I
2
C controller cannot generate a
START condition or the I
2
C SCL low time has expired the timeout value specified in I2CTO
register . This happens when the I
2
C controller is operating in master mode and some other
device on the bus is using the bus or holding SCL low for an extended period of time . This
bit must be cleared to 0 by software once set . Setting this bit to 1 by software causes an
interrupt if enabled .
I2CST.5 (I2CAMI)
I
2
C Slave Address Match Interrupt Flag. This bit is set to 1 when the I
2
C controller
receives an address that matches the contents in its slave address register (I2CSLA) during
the address stage . This bit must be cleared to 0 by software once set . Setting this bit to 1
by software causes an interrupt if enabled .
I2CST.6 (I2CALI)
I
2
C Arbitration Loss Flag. This bit is set to 1 when the I
2
C is configured as a master and
loses in the arbitration . When the master loses arbitration, the I2CMST bit is cleared to 0 .
Setting this bit to 1 by hardware causes an interrupt if enabled . This bit must be cleared to
0 by software once set . This bit is set by hardware only .
I2CST.7 (I2CNACKI)
I
2
C NACK Interrupt Flag. This bit is set to 1 if the I
2
C transmitter receives a NACK from the
receiver . Setting this bit to 1 by hardware causes an interrupt if enabled . This bit must be
cleared to 0 by software once set . This bit is set by hardware only .
I2CST.8 (I2CGCI)
I
2
C General Call Interrupt Flag. This bit is set to 1 when the general call is enabled
(I2CGCEN = 1) and the general call address is received . This bit must be cleared to 0 by
software once set . Setting this bit to 1 by software causes an interrupt if enabled .
I2CST.9 (I2CROI)
I
2
C Receiver Overrun Flag. This bit indicates a receive overrun when set to 1 . This bit
is set to 1 if the receiver has already received 2 bytes since the last CPU read . This bit is
cleared to 0 by software reading the I2CBUF . Setting this bit to 1 by software causes an
interrupt if enabled . Writing 0 to this bit does not clear the interrupt .
I2CST.10 (I2CSCL)
I
2
C SCL Status. This bit reflects the logic state of SCL signal . This bit is set to 1 when SCL
is at a logic-high (1), and cleared to 0 when SCL is at a logic-low (0) . This bit is controlled
by hardware and is read only .
I2CST.11 (I2CSPI)
I
2
C STOP Interrupt Flag. This bit is set to 1 when a STOP condition (P) is detected . This
bit must be cleared to 0 by software once set . Setting this bit to 1 by software causes an
interrupt if enabled .
I2CST.13 to I2CST.12
Reserved. Reads return 0.
