MAXQ612/MAXQ622 User’s Guide
Maxim Integrated 12-13
12.4.14 Endpoint 3 IN Byte Count Register (EP3BC)
Bit 7: Reserved. Reads returns zero.
Bits 6 to 0: EP3-IN Byte Count. This register contains the number of bytes the CPU has loaded into EP3 buffer for the
next IN transfer . Writing to the EP3BC register arms endpoint 3 for the next IN transfer .
12.4.15 Endpoint 0 Buffer Register (EP0BUF)
Bits 7 to 0: EP0 Buffer (EP0BUF[7:0]). These data register bits are used for reading/supplying data to the 64-byte
EP0 buffer for OUT and IN transfers to and from the bidirectional endpoint 0 .
For an IN transfer, the CPU writes a series of bytes to this EP0BUF to fill it with IN data . After filling the buffer with a
packet (0 to 64 bytes), the CPU writes the byte count register (EP0BC) to arm the IN transfer and to tell the SIE how
many bytes to transfer when it receives the IN packet to EP0 .
For an OUT transfer, the SIE fills the buffer with USB data received from the host . When the OUT transfer is verified to
be error-free, the SIE loads the byte count register (EP0BC) to indicate the number of bytes received in the OUT data
transfer . For a successful transfer the SIE also ACKs the OUT transfer and asserts the OUT0DAV interrupt request bit .
Note: This register is indetermistic on POR and retains its value on all other forms of reset.
Register Name EP3BC
Register Description Endpoint 3 IN Byte Count Register
Register Address UADDR[4:0] = 0Eh
Register Name EP0BUF
Register Description Endpoint 0 Buffer Register
Register Address UADDR[4:0] = 10h
Bit # 7 6 5 4 3 2 1 0
Name — EP3BC6 EP3BC5 EP3BC4 EP3BC3 EP3BC2 EP3BC1 EP3BC0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Name EP0BUF7 EP0BUF6 EP0BUF5 EP0BUF4 EP0BUF3 EP0BUF2 EP0BUF1 EP0BUF0
Reset s s s s s s s s
Access rw rw rw rw rw rw rw rw
