REGISTER DESCRIPTION
I2CCN.3:
Reserved. Read returns 0.
I2CCN.4 (I2CSTRS) I 2 C Clock Stretch Select. Setting this bit to 1 enables clock stretching after the falling edge of
the 8th clock cycle . Clearing this bit to 0 enables clock stretching after the falling edge of the
9th clock cycle . This bit has no effect when clock stretching is disabled (I2CSTREN = 0) .
I2CCN.5 (I2CACK) I 2 C Data Acknowledge Bit. This bit selects the acknowledge bit returned by the I 2 C
controller while acting as a receiver . Setting this bit to 1 generates a NACK (leaving SDA
high) . Clearing the I2CACK bit to 0 generates an ACK (pulling SDA LOW) during the
acknowledgement cycle . This bit retains its value unless changed by software or hardware .
When an I
2 C abort is in progress (I2CRST = 1), this bit is set to 1 by hardware and software
and writes to this bit are ignored when I2CRST = 1 .
I2CCN.6 (I2CSTART) I 2 C START Enable. Setting this bit automatically generates a START condition when
the bus is free or a repeated START condition during a transfer where the I 2 C module is
operating as the master . This bit automatically is self-cleared to 0 after the START condition
has been generated . If the I
2 C START interrupt is enabled, a START condition generates an
interrupt to the CPU .
In master mode, setting this bit may also start the timeout timer if enabled . If the timeout
timer expires before the START condition can be generated, a timeout interrupt will be
generated to the CPU if enabled . The I2CSTART bit will also be cleared to ‘0’ by the
timeout event .
Note that this bit has no effect when the I2C is operating in slave mode (I2CMST=0) and will
be reset to ‘0’ when I2CMST =0 or I2CEN=0 . Also the I2CSTART and I2CSTOP are mutually
exclusive . If both bits are set at the same time, it is considered as an invalid operation and
the I2C controller will ignore the request and reset both bits to 0 . Setting the I2CSTART bit
to 1 while I2CSTOP = 1 is an invalid operation and will be ignored, leaving I2CSTART bit
cleared to 0 .
I2CCN.7 (I2CSTOP) I 2 C STOP Enable. Setting this bit to 1 generates a STOP condition . This bit is automatically
self-cleared to 0 after the STOP condition has been generated .
In master mode, setting this bit may also start the timeout timer if enabled . If the timeout
timer expires before the STOP condition can be generated, a timeout interrupt will be
generated to the CPU if enabled . The I2CSTOP bit will also be cleared to ‘0’ by the timeout
event .
Note that this bit has no effect when the I2C is operating in slave mode (I2CMST=0) and will
be reset to ‘0’ when I2CMST=0 or I2CEN=0 . Setting the I2CSTOP bit to 1 while I2CSTART =
1 is an invalid operation and will be ignored, leaving I2CSTOP bit cleared to 0 .
I2CCN.8 (I2CGCEN) I 2 C General Call Enable. Setting this bit to 1 enables the I 2 C to respond to a general
call address (address = 0000 0000) . Clearing this bit to 0 disables the I 2 C to respond to
general call address .
I2CCN.9 (I2CSTREN) I 2 C Clock Stretch Enable. Setting this bit to 1 stretches the clock (hold SCL low) at the end
of the clock cycle specified in I2CSTRS . Clearing this bit disables clock stretching .
I2CCN.14:10 Reserved. Read returns 0.
I2CCN.15 (I2CRST) I 2 C Reset. Setting this bit to 1 aborts the current transaction and resets the I 2 C controller .
This bit is set to 1 by software and is only cleared to 0 by hardware after the reset or when
I2CEN = 0 .
