MAXQ612/MAXQ622 User’s Guide
5-6 Maxim Integrated
5.1 Peripheral Register Bit Descriptions
REGISTER DESCRIPTION
PO0 (00h, 00h) Port 0 Output Register (8-bit register)
Initialization: This register is set to 00h on all forms of reset .
Read/Write Access: Unrestricted read/write .
PO0.7 to PO0.0 Port 0 Output Register Bits 7:0. The PO0 register stores output data for port 0 when it is
defined as an output port and controls whether the internal weak p-channel pullup transistor
is enabled/disabled if a port pin is defined as an input . The contents of this register can be
modified by a write access . Reading from the register returns the contents of the register .
Changing the direction of port 0 does not change the data contents of the register .
PO1 (01h, 00h) Port 1 Output Register (8-bit register)
Initialization: This register is set to 00h on all forms of reset .
Read/Write Access: Unrestricted read/write .
PO1.7 to PO1.0 Port 1 Output Register Bits 7:0. The PO1 register stores output data for port 1 when it is
defined as an output port and controls whether the internal weak p-channel pullup transistor
is enabled/disabled if a port pin is defined as an input . The contents of this register can be
modified by a write access . Reading from the register returns the contents of the register .
Changing the direction of port 1 does not change the data contents of the register .
PO2 (02h, 00h) Port 2 Output Register (8-bit register)
Initialization: This register is set to 00h on all forms of reset .
Read/Write Access: Unrestricted read/write .
PO2.7 to PO2.0 Port 2 Output Register Bits 7:0. The PO2 register stores output data for port 2 when it is
defined as an output port and controls whether the internal weak p-channel pullup transistor
is enabled/disabled if a port pin is defined as an input . The contents of this register can be
modified by a write access . Reading from the register returns the contents of the register .
Changing the direction of port 2 does not change the data contents of the register .
PO3 (03h, 00h) Port 3 Output Register (8-bit register)
Initialization: This register is set to 00h on all forms of reset .
Read/Write Access: Unrestricted read/write .
PO3.7 to PO3.0 Port 3 Output Register Bits 7:0. The PO3 register stores output data for port 3 when it is
defined as an output port and controls whether the internal weak p-channel pullup transistor
is enabled/disabled if a port pin is defined as an input . The contents of this register can be
modified by a write access . Reading from the register returns the contents of the register .
Changing the direction of port 3 does not change the data contents of the register .
EIF0 (04h, 00h) External Interrupt Flag 0 Register
Initialization: EIF0 is cleared to 00h on all forms of reset .
Read/Write Access: Unrestricted read/write .
EIF0.7 to EIF0.0 (IE[7:0]) Interrupt Edge Detect Bits 7:0. These bits are set when a negative edge (ITn = 1) or
a positive edge (ITn = 0) is detected on the interrupt pin n . Setting any of the bits to 1
generates an interrupt to the CPU if the corresponding interrupt is enabled . The bit remains
set until cleared by software or a reset . It must be cleared by software before exiting the
interrupt source routine or another interrupt is generated as long as the bit remains set .
EIE0 (05h, 00h) External Interrupt Enable 0 Register
Initialization: EIE0 is cleared to 00h on all forms of reset .
Read/Write Access: Unrestricted read/write .
EIE0.7 to EIE0.0 (EX[7:0]) Enable External Interrupt Bits 7:0. Setting any of these bits to 1 enables the
corresponding external interrupt . Clearing any of the bits to 0 disables the corresponding
interrupt function .
