MAXQ612/MAXQ622 User’s Guide

5-24

Maxim Integrated

DESCRIPTION

SPICF1 (0Eh, 03h)

SPI Configuration Register 1

Initialization:

This buffer is cleared to 00h on all forms of reset .

Read/Write Access:

Unrestricted read/write .

SPICF1.0 (CKPOL)

Clock Polarity Select. This bit is used with the CKPHA bit to determine the SPI transfer

format . When the CKPOL is set to 1, the SPI uses the clock falling edge as an active edge .
When the CKPOL is cleared to 0, the SPI selects the clock rising edge as an active edge .

SPICF1.1 (CKPHA)

Clock Phase Select . This bit is used with the CKPOL bit to determine the SPI transfer

format . When the CKPHA is set to 1, the SPI samples input data at an inactive edge . When
the CKPHA is cleared to 0, the SPI samples input data at an active edge .

SPICF1.2 (CHR)

Character Length Bit. The CHR bit determines the character length for an SPI transfer

cycle . A character can consist 8 or 16 bits in length . When CHR bit is 0, the character is 8
bits; when CHR is set to 1, the character is 16 bits .

SPICF1.5 to SPICF1.3

Reserved . Reads return 0 .

SPICF1.6 (SAS)

Slave Active Select. This bit is used to determine the SSEL active state . When the SAS is

cleared to 0, the SSEL is active low and responds to an external low signal . When the SAS
is set to 1, the SSEL is active high .

SPICF1.7 (ESPII)

SPI Interrupt Enable . Setting this bit to 1 enables the SPI interrupt when MODF, WCOL,

ROVR, or SPIC flags are set . Clearing this bit to 0 disables the SPI interrupt .

SPICK1 (0Fh, 03h)

SPI Clock Register 1

Initialization:

This buffer is cleared to 00h on all forms of reset .

Read/Write Access:

Unrestricted read/write .

SPICK1.7 to SPICK1.0 (CKR[7:0])

Clock-Divide Ratio Bits 7:0. These bits select one of the 256 divide ratios (0 to 255) used

for the baud-rate generator, with bit 7 as the most significant bit . The frequency of the SPI
baud rate is calculated using the following equation:

SPI Baud Rate = 0 .5 x System Clock/(divide ratio + 1)

This register has no function when operating in slave mode and the clock generation
circuitry should be disabled .

I2CCN (00h, 04h)

C Control Register (16-bit register)

Initialization:

This register is cleared to 0000h on all forms of reset . The I2CSTART and I2CSTOP bits are
reset to 0 when I2CMST = 0 or when I2CEN = 0 . I2CSTART and I2CSTOP are a mutually
exclusive operation . User software can only set one of these bits at any given time . I2CRST
is reset to 0 when I2CEN = 0 .

Read/Write Access:

Unrestricted read . Unrestricted write access when I2CBUSY = 0 . Writes to I2CMST and
I2CMODE are ignored when I2CBUSY = 1 . Writes to I2CEN are normally disabled when
I2CBUSY = 1 . However, when the I2CRST = 1, I2CEN can be written to even when
I2CBUSY = 1 . Writes to I2CACK are ignored when I2CRST = 1 .

I2CCN.0 (I2CEN)

C Enable. This bit enables the I

C function . When set to 1, the I

C communication unit is

enabled . When cleared to 0, the I

C function is disabled .

I2CCN.1 (I2CMST)

C Master Mode Enable. The I2CMST bit functions as a master mode-enable bit for the

C module . When the I2CMST bit is set to 1, the I

C operates as a master . When the

I2CMST is cleared to 0, the I

C module operates in slave mode . This bit is automatically

cleared whenever the I

C controller receives a slave address match (I2CAMI = 1), loses

arbitration (I2CALI = 1), or through a general call (I2CGCI = 1) .

I2CCN.2 (I2CMODE)

C Transfer Mode . The transfer mode bit selects the direction of data transfer with respect

to the master . When the I2CMODE bit is set to 1, the master is operating in receiver mode
(reading from slave) . When the I2CMODE bit is cleared to 0, the master is operating in
transmitter mode (writing to slave) . Note that software writing to this bit is prohibited in slave
mode . When operating in master mode, software configures this bit to the desired direction
of data transfer . When operating in slave mode, the direction of data transfer is determined
by the R/W bit received during the address stage and this bit reflects the actual R/W bit
value in the current transfer and is set by hardware . Software writing to this bit in slave
mode is ignored .
