The MAXQ612/MAXQ622 support power-fail detection where an on-chip bandgap and reference comparator constant-
ly monitor the supply voltage V
DD to ensure that it is within acceptable limits . If V DD is below the power-fail level warn-
ing level, an interrupt is generated to the CPU if enabled . If V DD falls further to below the operating condition, the power
monitor initiates a reset condition . This can occur either when the MAXQ612/MAXQ622 are first powered up when the
V
DD supply is above the POR voltage threshold, or when V DD drops out of tolerance from an acceptable level .
In either case, the reset condition is maintained until V DD rises above the reset level V RST . Once (V DD > V RST ), there
is a delay of 8192 oscillator cycles until execution resumes to ensure that the clock source has stabilized .
Rather than leaving the power-fail reset monitoring circuit always on once the V
RST condition has occurred, it can be
advantageous to the application to conserve battery capacity during power-fail reset in order to extend the time until
POR is reached (and possibly retaining SRAM contents) . While there is still no single bit indicator that can be used to
guarantee SRAM retention once power-fail reset has occurred, one possibility is that the user can perform a checksum
over the area for which retention is questioned to make this assessment . So, in order to reduce current consumption
during the power-fail reset state, two power-fail reset check time configuration bits (PFRCK[1:0]) are provided for the
user . These bits are used to enable duty cycling of the V
RST power-monitoring circuitry during the time when V DD is
below the V RST threshold but has not reached the POR threshold . These bits are reset only by POR (not even V RST ) .
Table 2-9 provides the bit settings and corresponding duty cycling of the power monitor check when V
POR
< V
DD
<
V RST . Note that the V POR state for the bits is 00b, which results in the monitor being on always .
During the power-fail reset condition, duty cycling of the V RST power-monitoring circuitry results in reduced current that
can be approximated by the following equation:
I POWERFAIL = (3 x I S2 + (Check Interval Cycles - 3) x (I S1 + I NANO ))/Check Interval Cycles
where:
I
S1
= stop-mode current with power-fail monitor off
I S2 = stop-mode current with power-fail monitor on
I NANO = nanopower ring oscillator current
When the processor exits from the power-on/power-fail reset state, the POR bit in the watchdog control register
(WDCN) is set to 1 and can only be cleared by software . The user software can examine the POR bit following a reset
to determine whether the reset was caused by a power-on reset or by another source .
The power-fail monitor is always on during normal operation . However, it can be selectively disabled during stop
mode using the power-fail monitor disable (PFD) bit in the PWCN register if the regulator is also selectively disabled
(REGEN = 0) during stop mode . If the user opts to leave the regulator on during stop mode, the power-fail monitor is
automatically left enabled as well, regardless of the state of the PFD bit . The reset default state for the PFD bit is 0,
which enables the power-fail monitor function during stop mode . If power-fail monitoring is disabled (PFD = 1) during
stop mode, the circuitry responsible for generating a power-fail warning or reset is shut down and neither condition is
detected . Thus, the V
DD < V RST condition does not generate a reset . However, in the event that V DD falls below the
POR level, a POR is generated . The power-fail monitor is enabled prior to the stop mode exit and before code execu-
tion begins . If a power-fail warning condition (V
DD < V PFW ) is then detected, the power-fail interrupt flag is set on stop
mode exit . If a power-fail reset condition is detected (V DD < V RST ), the CPU goes into reset .
2.11.2 External Reset
During normal operation, the MAXQ612/MAXQ622 are placed into external reset mode by holding the RESET pin low
for at least four clock cycles . If the MAXQ612/MAXQ622 are in the low-power stop mode (i .e ., system clock is not
active), the RESET pin becomes an asynchronous source, forcing the reset state immediately after being taken low .
Once the MAXQ612/MAXQ622 enter reset mode, it remains in reset as long as the RESET pin is held low . After the
RESET pin returns to high, the processor exits the reset state within four clock cycles and begins program execution
from utility ROM at address 8000h .
The RESET pin is an output as well as an input . If a reset condition is caused by another source (such as a power-fail
reset or internal reset), an output reset pulse is generated at the RESET pin for as long as the MAXQ612/MAXQ622
remain in reset . If the RESET pin is connected to an RC reset circuit or a similar circuit, it may not be able to drive the
output reset signal; however, if this occurs, it does not affect the internal reset condition .
