Maxim Integrated MAXQ622 User Manual
Page 107
MAXQ612/MAXQ622 User’s Guide
Maxim Integrated
6-5
Bits 7:0: Port 3 Output. This register stores the data that is output on any of the pins of port 3 that have been defined
as output pins . If the port pins are in input mode, this register controls the weak pullup enable for each pin . Changing
the data direction of any pins for this port (through register PD3) does not affect the value in this register .
Bits 7:0: Port 4 Output. This register stores the data that is output on any of the pins of port 4 that have been defined
as output pins . If the port pins are in input mode, this register controls the weak pullup enable for each pin . Changing
the data direction of any pins for this port (through register PD4) does not affect the value in this register .
Bits 7:0: Port 5 Output. This register stores the data that is output on any of the pins of port 5 that have been defined
as output pins . If the port pins are in input mode, this register controls the weak pullup enable for each pin . Changing
the data direction of any pins for this port (through register PD5) does not affect the value in this register .
Bits 7:0: Port 6 Output. This register stores the data that is output on any of the pins of port 6 that have been defined
as output pins . If the port pins are in input mode, this register controls the weak pullup enable for each pin . Changing
the data direction of any pins for this port (through register PD6) does not affect the value in this register .
Register Name
PO3
Register Description
Port 3 Output Register
Register Address
M0[03h]
Bit #
7
6
5
4
3
2
1
0
Name
PO3 .7
PO3 .6
PO3 .5
PO3 .4
PO3 .3
PO3 .2
PO3 .1
PO3 .0
Reset
s
s
s
s
s
s
s
s
Access
rw
rw
rw
rw
rw
rw
rw
rw
Register Name
PO4
Register Description
Port 4 Output Register
Register Address
M1[04h]
Register Name
PO5
Register Description
Port 5 Output Register
Register Address
M1[01h]
Register Name
PO6
Register Description
Port 6 Output Register
Register Address
M1[02h]
Bit #
7
6
5
4
3
2
1
0
Name
PO4 .7
PO4 .6
PO4 .5
PO4 .4
PO4 .3
PO4 .2
PO4 .1
PO4 .0
Reset
s
s
s
s
s
s
s
s
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
PO5 .7
PO5 .6
PO5 .5
PO5 .4
PO5 .3
PO5 .2
PO5 .1
PO5 .0
Reset
s
s
s
s
s
s
s
s
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
PO6 .7
PO6 .6
PO6 .5
PO6 .4
PO6 .3
PO6 .2
PO6 .1
PO6 .0
Reset
s
s
s
s
s
s
s
s
Access
rw
rw
rw
rw
rw
rw
rw
rw
