OPERATOR’S MANUAL
IntelliAg MVT
11001-1643-201401
VEHICLE PREPARATION / 53
5. To display the number of seeds detected by each sensor, press the
Seed Count button.
– Stop button suspends the test
– Next Rows button displays next series of rows
– Count Reset button clears seed count
Figure 48
Seed Count Screen
TEST GROUND SPEED
Test Ground Speed is the ground speed reference used to perform the test.
ROW
Row is the active row configured in the system. The row that is set here is
the row that reports back a seed count in the Test Seed Count value. The
operator can change the row # to get the seed count of all rows during the
test.
TEST TARGET POPULATION
Test Target Pop is the seed rate at which the test is performed. This value
is the current target rate and is automatically populated.
TEST SEED COUNT
NOTE: Test Seed Count will
automatically reset whenever a
new Continuous Test is
performed. Test Seed Count is the seed count reported back on a specified row set in
the row data item and is automatically populated.
REMOTE TEST SWITCH
A momentary switch can be purchased from DICKEY-john that allows the
the control to be turned on/off during the Continuous and 5 Rev tests.
The switch allows the operator to go back to the implement to perform the
test and investigate mechanical issues or perform seed counts instead of
performing the test inside the cab from the Virtual Terminal. The test switch
will only function when the implement switch is in the up (off) position.
The remote test switch is to be connected to the actuator harness.
