OPERATOR’S MANUAL
IntelliAg MVT
11001-1643-201401
42 / MATERIAL SETUP
ON/OFF PATTERN
For split, twin, or skip row type seeding implements there are 21 predefined
patterns to configure row patterns. When a row pattern is selected, all of the
rows are automatically turned ON or OFF according to the pattern.
Individual rows in the Row Setup screen can still be manually edited to
Population, Blockage, or Off before or after a pattern is selected. The
pattern setting, when selected, will override previous individual existing row
settings.
ROW FAIL RATE
Sets the threshold for row failure alarms. The value is entered in seeds per
second. Both values are adjustable allowing for numerous combinations.
The default value is 2/1 that indicates a row failure threshold of 2 seeds in 1
second.
PATTERN Description/Example
…… Every Row On
-X-X-X Every 2nd Row Off
X-X-X- Every 2nd Row On
--X--X--X Every 3rd Row Off
-X--X--X- Every 3rd Row Off
X--X--X-- Every 3rd Row Off
XX-XX-XX- Every 3rd Row On
X-XX-XX-X Every 3rd Row On
-XX-XX-XX Every 3rd Row On
---X---X Every 4th Row Off
--X---X- Every 4th Row Off
-X---X-- Every 4th Row Off
X---X--- Every 4th Row Off
XXX-XXX- Every 4th Row On
XX-XXX-X Every 4th Row On
X-XXX-XX Every 4th Row On
-XXX-XXX Every 4th Row On
--XX--XX--XX Twin Rows
-XX--XX--XX- Twin Rows
XX--XX--XX-- Twin Rows
X--XX--XX--X Twin Rows
