OPERATOR’S MANUAL
IntelliAg MVT
11001-1643-201401
MATERIAL SETUP / 37
MATERIAL SETUP
The following parameters must be defined for effective system operation:
• Channel Setup
• Material Setup
• Ground Speed Setup and Calibration
• Module Configuration (Planter Control Module and Members)
CREATING A MATERIALS LIST
The Materials screen provides an overview of all materials assigned and
configured for a control channel. Unassigned materials appear with a
generic name of MATRL 1, etc.
Creating a material name allows for easy identification and displays
throughout various screens to identify the active material assigned to a
channel. Sixteen materials can be created for planter control.
To Create a Material Name:
1. At the Top Menu screen, press the Materials button.
2. At the Materials screen use the rotary knob to select and highlight the
material name.
– Push in the rotary knob to display the Material Configuration
screen.
3. Highlight the MATL NAME box and push in the rotary knob.
4. Use the virtual keyboard to type in the desired name.
5. Press the Check button to accept name and return to Material
Configuration screen.
NOTE: The whole name can be
entered at one time using the
virtual keyboard unlike the
keyboard used to enter a
password. Figure 35
Enter a Material Name
