OPERATOR’S MANUAL
IntelliAg MVT
11001-1643-201401
OPERATION / 99
DIAGNOSTICS
The Diagnostics screen provides various information from feedback
sensors, valve output, and system voltages of the planter control module.
The control valve can be manually opened on this screen when necessary.
Refer to the Vehicle Preparation/Valve Calibration section for additional
information.
Each channel has its own Diagnostics screen. None of the items on the
screen may be edited. However the Channel Pulse Count data is
resettable. The system can be active on the Diagnostics screen.
To View Diagnostics:
1. At the Main Work screen, verify the master/control switch (Control On)
button is off.
2. Press the Top Menu button.
3. Press the Next Page button.
4. Press the Diagnostics button.
5. At the Diagnostics screen, press the Control On button.
Figure 77
Diagnostics
