5Ć15 Functional Overview C3187Ć90000
PrintĆMode Characteristics
DesignJet 200
Media Type Print
Quality
Resolution
(DPI)
# of Passes Carriage
Speed
Swath
Delay Pass
Density
Paper Draft 300x300 1 24ips 0 50%
Final 300x300 1 16.7ips 1sec 100%
Vellum/
Transl
Draft 300x300 1 24ips 0 50%
Vellum/
Transl/Film
Final 300x300 2 16.7ips 1sec 50%
DesignJet 220
Media Type Print
Quality
Resolution
(DPI)
# of Passes Carriage
Speed
Swath
Delay Pass
Density
Paper Draft 300x300 1 24ips 0 50%
Final 300x300 1 16.7ips 1sec 100%
Enhanced addressable
600x600
2 16.7ips 0.5sec 50%
Vellum/
Transl
Draft 300x300 1 24ips 0 50%
Final 300x300 2 16.7ips 1sec 50%
Enhanced addressable
600x600
4 16.7ips 0.5sec 25%
Film Final 300x300 2 16.7ips 3sec 50%
Enhanced addressable
600x600
4 16.7ips 1.5sec 25%
A iw0tD is the amount of data printed in one pass of the carriage. The iw0tD 2bJ0y is the
time between completing one swath and beginning to print the next swath.
