8Ć17 Troubleshooting C3187Ć90000
Plotter won't Read Setup Sheet; Plots Solid Black Area Fill
This problem can occur on DesignJet 200 plotters with the oldĆstyle cartridge carriage.
Install a new carriage. (Details D chapter 9, w Chang in Carriag .)
Problems in Loading Media
User's Guide
The Troubleshooting section of the User's Guide lists mistakes you may be making if the
plotter continually rejects your media.
Long Media doesn't Load
DesignJet 200 plotters with firmware version A.01.00 cannot load 1.6Ćm media. Update the
firmware. (Details D chapter 9, w Probl ms Corr t d by irmwar R l as A.01.01.)
Translucent Media doesn't Load
Some DesignJet 200 carriage PCAs have problems sensing translucent media. The solution is
to install a new cartridge carriage. (Further Information D chapter 9, w Chang in Carriag .)
Binding, or Missing Sensor Flags
MediaĆload failures can also occur due to binding in the mediaĆaxis mechanics or missing
mediaĆsensor flags. Clear any binding in the mediaĆaxis mechanics due to a media jam. (Do
not pull the media along the carriage axis. Doing so could break the mediaĆsensor flags.)
Media Skews Badly
Ensure that the media diverters (part number D page 10Ć26) are correctly installed. If one is
missing or broken, replace it. To access this part, you need to remove the drive roller !
