10Ć18 Parts and Diagrams
C3187Ć90000
Parts List: CarriageĆAxis Drive (Right End)
Reference
Drawing
HP Part Number
Check
Digit
Quantity
Description
1
see page 10-21
1
Cartridge Carriage
2
C2847-00029
1
1
Main Drive Belt
(D/A1 Size)
1500-0856
7
1
(E/A0 Size)
3
see page 10-14
1
Trailing-Cable Front Tray
4
9170-1536
9
1
Ferrite Ring
5
C1633-80003
9
1
Blade Spring
6
0515-0380
2
4
Torx-15 Screw
7
07570-60112
0
1
Drive-Pulley Idler
8
07550-40104
4
1
Drive-Tensioner Cam
9
1460-2061
4
3
Drive-Tensioner Spring
10
0515-1349
5
1
M3 Machine Screw
11
07575-40125
8
1
Drive-Tensioner Bracket
12
C1633-00132
7
1
Encoder-Spring Bracket
13
C1633-60029
7
1
Y-Drive-Assembly Bracket
14
C1633-00002
0
1
Encoder Spring
15
C2858-60208
7
1
Encoder Strip
(D/A1 Size)
C2859-60208
8
1
(E/A0 Size)
16
3050-0026
0
3
Washer 3.2mm
17
0535-0031
2
2
Nut, Hex, W/LKWR M3
18
C1633-20034
0
1
Double-Pulley Bushing
19
1500-0855
6
1
Carriage-Axis Small Drive Belt
20
C3170-60009
7
1
Double Pulley
21
0515-2248
5
4
Y-Arm Screw
22
C2858-60206
5
1
Carriage Motor (includes item 26)
23
1400-0577
7
1
Cable Tie
24
See table opposite
Ferrite Assemblies
25
3050-1415
3
1
Washer
26
0515-0433
6
2
Screw, M4.0 X 0.7 X 8 mm
