HP 220 User Manual
Page 111
11 Loosen the YĆtensioner housing screw.
Torx-15
Loosen
12 Slide the YĆtensioner housing out from
the YĆtensioner bracket.
Y-tensioner
bracket
Y-tensioner
housing
13 Release the main idler from the
cartridgeĆcarriage belt.
14 Lift the YĆtensioner housing clear of the
plotter.
6Ć47
Removal and Replacement
C3187Ć90000
