10Ć8 Parts and Diagrams
C3187Ć90000
Parts List: Electronics Enclosure
Reference
on
Drawing
HP Part Number
Check
Digit
Quantity
Description
1
C3180-68102
9
1
Main PCA (New)
1
C3180-69102
1
Main PCA (Rebuilt, Exchange Assembly)
2
0515-2253
2
11
Machine Screw
3
See illustration
4 / 2
4 EPROMs or 2 Masked ROMs
4
C2064A
3
DRAM SIMM (Optional)
(2 Mbytes)
C2065A
4
(4 Mbytes)
C2066A
5
(8 Mbytes)
5
2200-0145
2
2
Machine Screw, 4-40
6
0570-1316
2
2
Female Screwlock (RS-232)
7
C3180-00003
7
1
Electronics Enclosure
(D/A1 Size)
C3181-00003
8
1
(E/A0 Size)
(Associated part: 8160-0770 RFI strip, attaches to the
enclosure to improve electromagnetic compatibility of
the plotter.)
8
1400-1648
5
1
Cable Clip
9
3160-0814
7
1
Tubeaxial Fan
10
0515-2405
6
2
Tapite Fan Screw
11
0950-2417
2
1
Power Supply
12
C3180-60006
6
1
AC Power Receptacle Assembly
13
0515-2149
5
4
Screw, M3.0X0.5X8
14
0515-2278
1
1
Torx-20 Screw
15
C2847-60005
9
1
Cable Assembly: Power supply to main PCA
16
C3180-60013
5
1
Power Supply Insulator (with label and tie)
17
C3180-00004
8
1
Electronics-enclosure Cover
(D/A1 Size)
C3181-00004
9
1
(E/A0 Size)
18
0515-2429
4
4
Torx-15 Screw
(D/A1 Size)
5
(E/A0 Size)
19
9170-1533
6
2
Ferrite Clamp
20
See page 10-6.
1
Trailing Cable
21
9170-1535
8
2
Split Ferrite
