A. Appliance Certification

C. High Altitude Installations

NOTICE: If the heating value of the gas has been reduced,

these rules do not apply. Check with your local gas utility

or authorities having jurisdiction.
When installing above 2000 ft. (610 m) elevation:
Reduce input rate 4% for each 1000 ft. (305 m) above

2000 ft. (610 m).

D. Non-Combustible Materials Specification

Material which will not ignite and burn. Such materials are

those consisting entirely of steel, iron, brick, tile, concrete,

slate, glass or plasters, or any combination thereof.

Materials that are reported as passing

ASTM E 136,

Standard Test Method for Behavior of Materials in a

Vertical Tube Furnace at 750 ºC (1382 °F) and UL763

shall be considered non-combustible materials.

E. Combustible Materials Specification

Materials made of or surfaced with wood, compressed pa-

per, plant fibers, plastics, or other material that can ignite

and burn, whether flame proofed or not, or plastered or

unplastered shall be considered combustible materials.

F. Electrical Codes

All electrical safety testing has been done following the EN

60335-2-102 standard. Local codes apply.

1

Listing and Code Approvals

MODELS: XLR-PLUS-N-AU, XLR-PLUS-PB-AU
LABORATORY:
SAI Global
TYPE:
Gas Space Heating Appliance
STANDARD:
AS4553:2008

The Heat & Glo gas appliances discussed in this Installer’s

Guide have been tested to certification standards and listed

by the applicable laboratories.

This appliance must be installed in accordance with the

rules in force.

NOX Class 5 for G20, NOX Class 5 for G31

B. Gas Pressure Requirements

Pressure requirements for XLR-PLUS fireplaces are

shown in table below.
Two taps are provided on the right hand side of the gas

control for a test gauge connection to measure the inlet

and outlet pressures.
The fireplace and its individual shut-off valve must be dis-

connected from the gas supply piping system during any

pressure testing of the system at test pressures in excess

of 3.4 kPa.
If the fireplace must be isolated from the gas supply pip-

ing system by closing an individual shut-off valve, it must

be of the handle-less type.

Natural Gas

Propane

Butane

Inlet Gas Pressure

1.13 - 3.40 kPa

2.75 - 3.40 kPa

2.75 - 3.40 kPa

Outlet (Manifold) Gas Pressure

.80 - .95 kPa

2.36 - 2.61 kPa

2.36 - 2.61 kPa

Gas Rate

.405

m3

/

h

.134

m3

/

h

.111

m3

/

h

Maximum Gas Consumption

26 MJ/h

26 MJ/h

22 MJ/h

Burner Injector

DMS 42 (2.350 mm)

DMS .057 (1.450 mm)

DMS 55 (1.325)

Pilot Injector

Ø .023 (.584 mm)

Ø .014 (.356 mm)

Ø .010 (.254 mm)

Columns highlighted in gray = The gas control valve supplied with this product is approved for a maximum

inlet pressure of

3.40 kPa. For pressures over 3.40 kPa, an in line pressure regulator must be installed

upstream from the gas control valve.
