29 Heat & Glo • XLR-PLUS-N-AU, XLR-PLUS-PB-AU • 2264-900 Rev. o • 1/13
INSTALLED
HORIZONTALLY
H
1
H
2 V
1
V
2
Figure 7.9
Top Vent - Vertical Termination
Venting with 3 elbows
Note: Use SLP Series
components only.
V
1
Minimum H
1
+ H
2
Maximum V
2
V
1
+ V
2
Minimum
90° Elbow 1 ft. (305 mm) * *
1 ft. (305 mm) 2 ft (610 mm) * *
2 ft. (610 mm) 5 ft. (1.2 m) * *
3 ft. (914 mm) 6 ft. (1.8 m) * *
4 ft. (1.2 m) 14 ft. (4.3 m) * *
H Max. = 14 ft. (4.3 m)
V
1
+ V
2
+ H
1
+ H
2
Max. = 40 ft. (12.2 m)
* No specific restrictions on this value EXCEPT V
1
+ V
2
+ H
1
+ H
2
cannot exceed 40 ft. (12.2 m)
Note: All appliances that will burn butane must have
a 12 in. (305 mm) vertical section of pipe before
any other venting.
