Top Vent - Vertical Termination
Venting with 4 elbows
Note: Use SLP Series
components only.
V
1
Min. H
1
Max. V
2
Min. H
2
Max. V
3
Min.
18 in. (457 mm) 5 ft. (1.2 m) 5 ft. (1.2 m) 5 ft. (1.2 m) 3 ft. (1.0 m)
V
1
+ V
2
+ V
3 +
H
1
+ H
2
Maximum= 40 ft. (12.2 m)
V
1
H
1
V
2
V
3
H
2
Figure 7.10
Note: All appliances that will burn butane must have
a 12 in. (305 mm) vertical section of pipe before
any other venting.
