Operator Control and Display Panel
68
Settings
Display contrast Adjust the LCD display contrast
Date format set Choose the format for date display: M/D/Y, D/M/Y, M/D/Y, Y/M/D
Date & time Set the date and time
Comm1 baud rate Communication baud rate setting for Intellislot 1
Comm2 baud rate Communication baud rate setting for Intellislot 2
Comm3 baud rate Communication baud rate setting for Intellislot 3
Communication address This setting is applicable to RS485 communication mode
Communication mode Communication Mode Setting
Callback times When Intellislot 1 Communication mode is Modem, this parameter sets the
number of times a number is redialed to send an alarm notification.
Phone No.1 When Intellislot 1 Communication mode is Modem, this is the first phone
number to be dialed (to send an alarm notification).
Phone No.2 When Intellislot 1 Communication mode is Modem, this is the second phone
number to be dialed (to send an alarm notification).
Phone No.3 When Intellislot 1 Communication mode is Modem, this is the third phone
number to be dialed (to send an alarm notification).
Command password User can modify the command password.
Command
(start/stop
battery &
system
tests)
Battery maintenance test This test performs a partial discharge of the battery to obtain a rough estimate
of the battery capacity. Load must be between 20% and 80%.
Battery capacity test This test performs a full discharge of the battery to obtain a precise measure of
the battery capacity. Load must be between 20% and 80%.
System test This is a self-test of the UPS. When the user activates this function, a pop-up
window appears about 5 seconds later to show the results.
Stop testing Manually stops a battery maintenance test, battery capacity test or system
test.
Freshening Charge Allows a temporary Equalize charge for the batteries. This charge is
configurable for 1 to 36 hours.
Stop Freshening Charge Manually stops a Freshening Charge
Modem Auto-answer
enable
Manually enable the modem’s auto-answer function.
Version
UPS version Provides UPS firmware version numbers for the inverter, rectifier and software
display board.
UPS model Provides UPS model information—for example, 208V-60Hz.
Table 22 Descriptions of UPS menus and data window items (continued)
Menu Type Item Type Explanation
