Specifications and Technical Data
95
Table 39 Battery cabinet physical characteristics
Battery Cabinet
Type
Dimensions
WxDxH in. (mm)
Net Weight Without
Batteries, lb. (kg)
Short Narrow
27.2x31.4x63
(690x825x1600)
551
(250)
Short Wide
58.5x31.4x63
(1488x825x1600)
889
(400)
Table 40 Maintenance Bypass Cabinet weights
UPS
Rating
Maintenance Bypass Cabinet Style, lb. (kg)
A B C D E F J K L M N P
10kVA
408
(185)
545
(247)
675
(306)
602
(273)
732
(332)
630
(286)
403
(183)
540
(245)
670
(304)
597
(271)
728
(330)
630
(286)
15kVA
408
(185)
567
(257)
728
(330)
659
(299)
822
(373)
680
(308)
403
(183)
562
(255)
723
(328)
655
(297)
818
(371)
680
(308)
20kVA
408
(185)
646
(293)
842
(382)
739
(335)
935
(424)
750
(340)
403
(183)
642
(291)
838
(380)
734
(333)
930
(422)
750
(340)
30kVA
408
(185)
694
(315)
893
(405)
807
(366)
1027
(466)
840
(381)
403
(183)
690
(313)
888
(403)
802
(364)
1023
(464)
840
(381)
Table 41 Maintenance bypass cabinet dimensions
Unit Width Depth Height
inch 27.2 31.4 63
mm 690 825 1600
Table 42 Multi-module paralleling cabinet dimensions
1+1 Cabinet Type Width Depth Height
1+N Narrow 27.2 31.4 63
Types A00, BR0, CR1, DR1 690 825 1600
1+N Cabinet Type Width Depth Height
1+N Narrow 27.2 31.4 63
Types A00, E00, J00 690 825 1600
1+N Wide 58.5 31.4 63
All other types 1488 825 1600
