Option Installations
39
5.10 OC Web Card—SNMP/HTTP Network Interface Card
This network interface card provides all real-time data and status information as SNMPv1 traps for
connection to a 10/100-baseT Ethernet connection. The same card also will transmit the same status
information and all measured parameters for display via a Web browser.
Table 8
NX communication options
Physical
description
of port
Labeled
ID Name
of Port
On the UPS
LCD screen,
under Settings,
controlled by:
Monitoring
Devices
supported
Baud
rate Comments
Top
Intellislot
Intellislot 1
(On Monitor Board)
Comm 1
Multiport 4 any
Relaycard-int any
OCWEB-LB
2400
Not simultaneous with
Multilink in RS232-1
Modbus/Jbus 2400
Middle
Intellislot
Intellislot 2
(On Monitor Board)
Comm 2
Multiport 4 any
Relaycard-int any
OCWEB-LB
2400
Not simultaneous with
Multilink in RS232-2
Modbus/Jbus 2400
Bottom
Intellislot
Intellislot 3
(On Monitor Board)
Comm 3
Multiport 4 any
Relaycard-int any
OCWEB-LB 2400
Modbus/Jbus 2400
Top
DB9 port
RS232-1 Comm 1
Multilink Serial
9600
Not simultaneous with Web
card in top intellislot.
Bottom
DB9 port
RS232-2 Comm 2
Service Software
(Reserved)
9600
Not simultaneous with Web
card in middle intellislot.
