UPS Status Messages
97
A
PPENDIX
A - UPS S
TATUS
M
ESSAGES
Table 44 shows all event messages as they appear in the current status area of the LCD or the his-
tory log, along with a description and recommended actions, if any. For further information on the
current status area and the history log, see 2.11 - UPS Status Messages.
Table 44 UPS status messages
Event Message Description / Suggested Action (if any)
Inverter Comm. Fail
The RS485 communication between internal monitor and inverter fails. Contact Liebert Global
Services at 800-543-2378 for assistance.
Rectifier Comm. Fail
The RS485 communication between internal monitor and rectifier fails. Contact Liebert Global
Services at 800-543-2378 for assistance.
Parallel Comm. Fail
The CAN communication between different UPSs within a parallel system fails.
1. Check if there are some UPSes not powered on in the parallel system. If so, power on these
UPSs and check if the alarm disappears.
2. Press Fault Clear push button.
3. If alarm does not clear, contact Liebert Global Services at 800-543-2378
Battery Overtemp. The Battery temperature is over limit. Check the battery temperature and ventilation
Ambient Overtemp. The Ambient temperature is over limit. Check the ventilation of UPS room.
Battery Fault Battery is bad. (Reserved) Contact Liebert Global Services at 800-543-2378 for assistance.
Replace Battery Battery should be replaced. Contact Liebert Global Services at 800-543-2378 for assistance.
Battery Low Pre-warning
Before the end of discharging, battery under-voltage pre-warning should occur. After this pre-
warning, battery should have the capacity for 3 minutes discharging with full load. The time is
user configured from 3 to 60 minutes.
Shut down the load in time
Battery End of Discharge
Inverter turned off due to low battery voltage.
Check the utility failure and try to recover it.
Mains Volt. Abnormal
Mains Voltage exceeds the upper or lower limit and results in rectifier shutdown.
Check the input line-to-neutral voltage amplitude of rectifier.
Mains Undervoltage
Mains Voltage is undervoltage (120v~176v) with derated load.
Check the input line-to-line voltage amplitude of rectifier.
Mains Freq. Abnormal
Mains frequency is out of limit range and results in rectifier shutdown.
Check the rectifier’s input voltage frequency
Battery Fuse Fail Battery Fuse is open. Contact Liebert Global Services at 800-543-2378 for assistance.
Rectifier Fault Rectifier Fault; Contact Liebert Global Services at 800-543-2378 for assistance.
Input Inductor Overtemp.
The temperature of rectifier inductor is too high to keep the rectifier running.
Check the ambient temperature and ventilation; contact Liebert Global Services at
800-543-2378 for assistance.
Rectifier Overtemp.
The temperature of heat sink is too high to keep the rectifier running.
The UPS can recover automatically. Check the environment and ventilation.
Charger Fault The Charger is fault. Contact Liebert Global Services at 800-543-2378 for assistance.
Input Fuse Fail Input fuse is open. Contact Liebert Global Services at 800-543-2378 for assistance.
Control Power 1 Fail
Control Power 1 has failed or has been lost. Contact Liebert Global Services at 800-543-2378 for
assistance.
Mains Phase Reversed
Input phase sequence is inverse. Contact Liebert Global Services at 800-543-2378 for
assistance.
Rectifier Overcurrent
The current of Rectifier is over limit. Contact Liebert Global Services at 800-543-2378 for
assistance.
Soft Start Fail
Rectifier could not start due to low DC bus voltage. Contact Liebert Global Services at
800-543-2378 for assistance.
