16
RiverMaster Administrator’s Guide
Checking Server Status
Chapter 2
Getting Started with RiverMaster
Figure 8 Aurorean Network Gateway Status Information
Aurorean Network Gateway Statistics
Figure 9 shows the statistics information RiverMaster displays for the
Aurorean Network Gateway. The graph indicates total amount of bytes sent
and received over all tunnels processed by the Aurorean Network Gateway;
to view the traffic passing over a single tunnel, click the button at the top right
corner of the graph.
Indicates current alarms,
Click here to view
more details about
logged in users
alerts, and informational
messages that appear in
the System Activity window
(refer to Chapter 7 for more
information)
Total number of remote
users authenticated and
connected to the corporate
network via the Aurorean
Network Gateway
