S1C88650 TECHNICAL MANUAL EPSON 171
APPENDIX A S5U1C88000P1&S5U1C88649P2 MANUAL (Peripheral Circuit Board for S1C88650)
A.4 Product Specifications
The components specifications of the S5U1C88649P2
are listed below.
S5U1C88649P2
Dimensions (mm):
184 (W)
×
152 (D)
×
17 (H)
I/O cable (100-pin/50-pin x 2)
S5U1C88649P2 connector (100-pin):
KEL 8830E-100-170L
Cable connector (100-pin):
KEL 8822E-100-170L
×
1
Cable connector (50-pin):
Connector 3M 7950-B500SC
×
2
Strain relief 3M 3448-7950
×
2
Cable:
50-pin flat cable
×
1
Interface:
CMOS interface (3.3 V)
Length:
Approx. 40 cm
I/O cable (40-pin/20-pin x 2)
S5U1C88649P2 connector (40-pin):
KEL 8830E-040-170L
Cable connector (40-pin):
KEL 8822E-040-170L
×
1
Cable connector (20-pin):
Connector 3M 7920-B500SC
×
2
Strain relief 3M 3448-7920
×
2
Cable:
20-pin flat cable
×
1
Interface:
CMOS interface (3.3 V)
Length:
Approx. 40 cm
Accessories
50-pin connector for the target system:
3M 3433-6002LCSC
×
2
20-pin connector for the target system:
3M 3428-6002LCSC
Ч
2
