150 EPSON S1C88650 TECHNICAL MANUAL
8 ELECTRICAL CHARACTERISTICS
8.8 Characteristics Curves (reference value)
■ High level output current-voltage characteristic
Ta = 70°C, Max. value
0.0
0
-3
-6
-9
-12
-15
0.2 0.4 0.6 0.8 1.0
V DD –V OH [V]
V DD = 1.8 V
V DD = 2.4 V V DD = 3.6 V
I OH
[mA]
■ Low level output current-voltage characteristic
Ta = 70°C, Min. value
0.0
15
12
9
6
3
0
0.1 0.2 0.3 0.4 0.5 0.6
V OL [V]
V DD = 1.8 V V DD = 3.6 V
I OL
[mA]
V DD = 2.4 V
