144 EPSON S1C88650 TECHNICAL MANUAL
8 ELECTRICAL CHARACTERISTICS
8.6 AC Characteristics
■ Operating range
Condition: V DD = 1.8 to 3.6 V, V SS = 0 V, Ta = -20 to 70
°
C
Item Symbol Min. Typ. Max. Unit Condition
Operating frequency
Instruction execution time
(during operation with OSC1 clock)
Instruction execution time
(during operation with OSC3 clock)
f OSC1
f OSC3
t cy
t cy
30
0.03
10
20
30
40
50
60
0.24
0.49
0.73
0.98
1.22
1.46
32.768
61
122
183
244
305
366
200
8.2
67
133
200
267
333
400
66.7
133.3
200.0
266.7
333.3
400.0
kHz
MHz
µ
s
µ
s
µ
s
µ
s
µ
s
µ
s
µ
s
µ
s
µ
s
µ
s
µ
s
µ
s
V DD = 1.8 to 3.6 V
1-cycle instruction
2-cycle instruction
3-cycle instruction
4-cycle instruction
5-cycle instruction
6-cycle instruction
1-cycle instruction
2-cycle instruction
3-cycle instruction
4-cycle instruction
5-cycle instruction
6-cycle instruction
Note
