5 PERIPHERAL CIRCUITS AND THEIR OPERATION (LCD Driver)
DBON: 00FF03H•D0
Control the power voltage booster circuit.
When "1" is written: ON
When "0" is written: OFF
Reading:
Valid
When "1" is written to DBON, the power voltage
booster activates and almost doubles the V
DD
voltage to generate the V D2 voltage. Turn the power
voltage booster on when driving the LCD system
voltage regulator with V
D2 .
When "0" is written to DBON, the power voltage
booster goes off. When driving the LCD system
voltage regulator with V
DD , turn the power voltage
booster off to reduce current consumption.
At initial reset, DBON is set to "0" (OFF).
VDSEL: 00FF03H•D1
Selects the power voltage for the LCD system
voltage regulator.
When "1" is written: V D2
When "0" is written: V DD
Reading: Valid
When "1" is written to VDSEL, the LCD system
voltage regulator is driven with V
D2 generated by
the power voltage booster. Before this setting is
made, it is necessary to write "1" to DBON to turn
on the power voltage booster. Furthermore, do not
switch the power voltage to V
D2 for at least 1 msec
after the power voltage booster is turned on to
allow V
D2 stabilize.
When "0" is written to VDSEL, the LCD system
voltage regulator is driven with V
DD .
At initial reset, VDSEL is set to "0" (V DD ).
5.11.8 Programming notes
(1) When the SLP instruction is executed, display
control registers LCDC0 and LCDC1 are
automatically reset to "0" by hardware.
(2) When driving the LCD system voltage regulator
with V D2 , wait at least 1 msec for stabilization of
the voltage before switching the power voltage
for the LCD system voltage regulator to V
D2
using VDSEL after the power voltage booster is
turned on.
