8 ELECTRICAL CHARACTERISTICS
■
Oscillation frequency resistor characteristic (OSC1)
Ta = 25°C, Typ. value
100
1000
100
10
1000
10000
R
CR1
[k
Ω
]
f
OSC1
[kHz]
■
Oscillation frequency temperature characteristic (OSC1)
Typ. value, R
CR1
= 1500 k
Ω
-50
1000
100
10
25
-25
50
0
75
100
Ta [
°
C]
f
OSC1
[kHz]
